Creative Geometric LED Display

» Creative Geometric LED Display

  • face mask shape led display

    CATEGORY AND TAGS:
    Creative Geometric LED Display, Night club LED display , , , , , ,

    creative mask shape LED display

    for nightclub DJ/VJ background

    music festival

    event rental

    company showroom

    enquiry
    • Description
    • specification

    Face mask shape LED display is a unique design from visualpower which can show dynamic mapped video on the surface of a human face shape led display.

    It can be widely used for nightclub design, museums, shopping malls and so on.

    as an eye-catcher and media tool, it is the combination of led display technology and video art.

    combination with creative DJ and VJ booth display for creative nightclub design.

    Dimension:

    Application: nightclub design, creative interior design

    P4 face mask display SPECIFICATION
    Product Name P4 indoor mask shape LED Display
    Model P4
    Pixel pitch 4mm
    Pixel configuration SMD2121
    Pixel Density 62500 dots/㎡
    Scan rate  1/16scan
    Module size(W×H) customized
    Module Resolution customized
    Cabinet size(mm) W1482.99*H2199.67*D350.59mm
    Minimum viewing distance  4m
    Viewing angle(degree H/V)  H/160,V/140
    White balance brightness 800CD/M2(nits)
    Gray scale  12 bit, 40962steps
    Refresh rate  ≥3840HZ
    Maintenance way Front
    Cabinet Material Iron
    Display resolution W711xH633pixels
    Total N.W 150KGS
    Total G.W 227KGS
    Packing size L225*W158*H64cm
    Working Voltage AC200-240V
    Max.Power Consumption  2500W
    Working temperature -25℃ to +60℃
    Working humidty 10%-80%
    Protection Level  Front: IP43 Rear: IP31
    Lifetime 75,000hr
    LED Failure Rate  <0,00001
    MTBF  > 10.000 hours
    Display Mode Synchronous with video source
    Input Signal DVI HDMI
