outdoor flexible led display module
320*160mm
compatible model: P2.5, P3, P4, P5
for column, curved shape, convex, concave
creative shape outdoor LED display
enquiryOutdoor flexible module is widely used for special shapes such as curve, convex, concave, column shape.
compared to common rigid modules, it can bend certain degree and make the shapes that normal modules can not do.
by uniform module size of W320*H160mm and compatible with differnet models of P2.5, P3,P4, P5, it can be used for most outdoor special shape led displays.
Model | P2.5 | P3 | P4 | P5 |
Pixel pitch | 2.5mm | 3.076mm | 4mm | 5mm |
LED type | SMD1415 | SMD1415 | SMD1921 | SMD1921 |
Module size | 320x160mm | 320x160mm | 320x160mm | 320x160mm |
Module resolution | 128X64pixels | 104X52pixels | 80X40pixels | 64X32pixels |
Pixel density | 160000/m2 | 105625/m2 | 62500/m2 | 40000/m2 |
Scan number | ≥5000Cd/m2 | ≥5000Cd/m2 | ≥5000Cd/m2 | ≥5000Cd/m2 |
Scan number | 1/16S | 1/13S | 1/10S | 1/8S |
Refresh rate | ≥3840HZ | ≥3840HZ | ≥3840HZ | ≥3840HZ |
Drive mode | Constant current | Constant current | Constant current | Constant current |
Max. power/sqm | 800w | 800W | 600W | 600W |
Ave.power/sqm | 270W | 270W | 210W | 210W |
Module weight | 460g | 460g | 460g | 460g |
Working voltage | DC4.2-5V | DC4.2-5V | DC4.2-5V | DC4.2-5V |
IP rate | IP65 | IP65 | IP65 | IP65 |
