    • Description
    • Specification

    visualpower VC sereis COB LED display is a high end design which is widely used for control room, meeting room.TV stations and so on.

    with common cathode energy saving design, it generates less heat and have better white balance. brightness over 1000nits

    Model VC-P0.9 VC-P1.25 VC-P1.5
    LED Parameters Encapsulation Flip Chip COB Flip Chip COB Flip Chip COB
    Chip Bonding Method Wire Free Wire Free Wire Free
    Pixel Pitch (mm) 0.93 1.25 1.56
    Pixel Density (Pixel/m2) 1137777 640000 409600
    Drive Mode PWM PWM PWM
    Cabinet Parameters Cabinet Size (W×H×D) (mm) 600×337.5×44.5 600×337.5×44.5 600×337.5×44.5
    Cabinet Resolution (W×H) (Px) 640×360 480×270 384×216
    Area for Single Cabinet (m2) 0.2025 0.2025 0.2025
    Flatness (mm) ≤0.1 ≤0.1 ≤0.1
    Cabinet Weight (kg) 4.8±0.1 4.8±0.1 4.8±0.1
    Module Connection Method Wire Free Wire Free Wire Free
    Maintenance Front Front Front
    Cabinet Material Die-casting Alumium Die-casting Alumium Die-casting Alumium
    Ingress Protection IP65 IP65 front IP65
    Optical Parameters Operation Brightness (cd/m2) 0-1200 Adjustable 0-1200 Adjustable 0-1200 Adjustable
    Brightness Calibration Support Support Support
    Chroma Calibration Support Support Support
    Storage for Calibration Coefficient Flash on Modules Flash on Modules Flash on Modules
    Brightness Uniformity ≥98% ≥97% ≥98%
    Refresh Rate (Hz) 3840 3840 3840
    Color TEMP Range (K) 2000-10000 2000-10000 2000-10000
    Color Gamut ≥115% ≥115% ≥115%
    Color 281 trillion colors 281 trillion colors 281 Trillion Colors
    Horizontal Viewing Angle (°） ≥170 ≥170 ≥170
    Vertical Viewing Angle (°） ≥170 ≥170 ≥170
    Static Contrast ≥10000:1 ≥30000:1 ≥30000:1
    Dynamic Contrast ≥300000:1 ≥300000:1 ≥300000:1
    Electrical Parameters Power Supply (V) AC 100-240V（50/60Hz） AC 100-240V（50/60Hz） AC 100-240V（50/60Hz）
    Max Power Consumption (W/ m2) ≤360@1200nit ≤340@1200nit ≤320@1200nit
    ≤230@600nit ≤210@600nit ≤190@600nit
    Image Processing Gray Scale (bit) >14-16 >14-16 >14-16
    Brightness Control Grade 256 256 256
    Frame Frequency (Hz) 50/60 50/60 50/60
    Operation Parameters Use TEMP/Humidity (℃/RH) -10～+40 / 10% ～ 90% no condensation -10～+40 / 10% ～ 90% no condensation -10～+40 / 10% ～ 90% no condensation
    Storage TEMP /Humidity (℃/RH) -20～+60 / 10% ～ 90% no condensation -20～+60 / 10% ～ 90% no condensation -20～+60 / 10% ～ 90% no condensation
    LED Chips Typical Lifespan (Hrs) 100000 100000 100000
    Notice: Parameters can be customized according to the actual situation, we reserve all the right for the final explanation.
